I'm not sure if soldering, installing resistors and adjusting a circuit board in such a way is in my skill set. I have no experience 😜
Here's a close up pic of JP10 which is a kind of connector.
I have copy and pasted the last entry in the manual which is in regards to setting the voltage with JP10. See below.
Seems like this board from 1995 has no on board voltage regulator - I really picked a bad board 🙁
No VR-100 and VR-102 on ebay - this will take some time.....
MANUAL LAST ENTRY:
CPU VOLTAGE
Setting
JP10
3.3v
VR-100/VR-102 installed
3.45v
VR-100/VR-102 installed
3.6v
VR-100/VR-102 installed
4v
VR-100/VR-102 installed
5v
1 & 2, 3 & 4, 5 & 6, 7 & 8, 9 & 10, 11& 12, 13 & 14, 15 & 16, 17 & 18, 19 & 20
Note: Pins designated should be in the closed position.
http://stason.org/TULARC/pc/motherboards/E/EL … ml#.UYJq_ErxRD0
See an earlier revision had JP31 to set voltage. My board is missing that jumper. See the bottom of this link. http://stason.org/TULARC/pc/motherboards/E/EL … ml#.UYKlqkrxRD0
Off topic and on a happier note here is the new case I scored:
Whipped out the Pentium 166MMX board and chip.
